> Resettable design, obvious indicators around the edges of the unit. > Press the pressing plate to enable the output function. > Pressing plate with status (green and red) shown. > Reversionary key with non-slip design. > Input power range from DC12-24V to connect with all types of fire alarm system. > Built-in buzzer status to set as silent, interval wailing or continuous wailing volume is adjustable. > Easy to asseble, outer case without screws, 3 set of output points to connect other equipment, embedded or surface installations to select.
Specification
• Dimension : 90(L) x 93(W) x 64(H) mm • Power Supply : DC12V - 24V • Operation Current : DC12V/18mA (Standby) / 75mA (Operation) DC24V/11mA (Standby) / 41mA (Operation) • Buzzer : Set as silent, interval wailing or continuous wailing • Indicator : Dual-colour (red and green) Red indicator to set blinking, off or no • Output : NO, NC & COM. Output (Max. load of 125V/3A) • Weight : 192g • Material : ABS, PC (Transparent part)
