> Suitable for outdoor use > Locking mechanism for large gates
Specification
• Input operating voltage : 12-24 V DC • Rated operating voltage tolerance range : ± 15 % • 12 V starting current : 1000 mA • 24 V starting current : 500 mA • 12 V latching current : 40 mA • 24 V latching current : 30 mA • Holding power : 50000 N • Diameter lock deadbolt : 18 mm • Lock bolt throw : 30 mm • Length : 150 mm • Width : 80 mm • Height : 80 mm • Installation position : Vertical and horizontally (closed downwards only)
