Biometric Reader Fingerprint Access Control Standalone Terminal ENID
Home /
Biometric Reader
Fingerprint Access Control Standalone Terminal
SI-FP-03
Biometric access controller for doors and time attendance clock machine with fingerprint security through web-based. SI-FP-03 features standard TCP/IP and RS485 interfaces for main communication between devices and the server. SI-FP-03 features an IP54 certified weatherproof exterior. IP54 protection allows system designers to place the terminal in both indoor and outdoor environments.
Feature & Specification
Biometric Reader Fingerprint Access Control Standalone Terminal 1 ~blog/2022/6/7/fp031
Biometric Reader Fingerprint Access Control Standalone Terminal 2 ~blog/2022/6/7/fp032
Biometric Reader Fingerprint Access Control Standalone Terminal 3 ~blog/2022/6/7/fp033
  • Features
  • Specification

    • Specification

    • Verification Mode : Fingerprint/Card
    • Software Application : Software/Browser
    • Template Capacity : 9,590
    • Sensor Type : Optical
    • Resolution : 500dpi
    • Sensing Area : 16 x 19mm
    • Template Size : 256~384 Bytes
    • Image Size : 272 x 320 (pixel)
    • 1:1 Verification time : <600msec
    • 1:1,000 Identification time : <760msec
    • Card Capacity : 20,000
    • Communications : TCP/IP, Wiegand/RS485
    • DIO Support: DI : 3/DO: 1
    • Inbuilt Relays (Max. Power Loading) : (1) Door Lock (40VAC/40VDC,2A)
    • System Log : 1,536 entries
    • Entry Log : 51,968 entries
    • Time Set / Time Zone / Group : 255 / 120 / 255 sets
    • Holiday : Yes
    • Remote Control / Event Handle : Yes / Yes
    • Fast Registry : Yes
    • Anti-Pass Back / Anti Duress : Yes / Yes
    • Power Consumption : 500mA ± 5%
    • Power Requirement : 9 ~ 24VDC / 1A
    • Operation Temperature : 0°C ~ 65°C
    • Operation Humidity : 5% ~ 80% RH
    • Dimension / Weight : 160 x 56.9 x 40.1mm / 150g

Download
Fingerprint Access Control Standalone Terminal 1
