UHF Windshield Tag - Long-range Vehicle Identification Tag
994xxxx
The UHF Windshield Tag is a vehicle identification tag. It offers cost effective long-range identification for parking applications. Based on passive UHF technology (± 900 MHz), the UHF Windshield Tag is identified up to 10 meters (33 ft) with uPASS Target or 5 meters (16 ft) with uPASS Reach. The tag does not contain a battery and is maintenance free.
Feature & Specification
Card & Credential UHF Windshield Tag - Long-range Vehicle Identification Tag 1 ~blog/2022/6/15/wintag
  • Features
  • Specification

    • Specification

    • Part number : 9945954 UHF Windshield Tag Wiegand 26, 9947418 UHF Windshield Tag Wiegand 26 (US), 9945946 UHF Windshield Tag, 9942335 UHF Windshield Tag Tamper Resistant Wiegand 26, 9947426 UHF Windshield Tag Tamper Resistant Wiegand 26 (US), 9946918 UHF Windshield Tag Tamper Resistant
    • Dimensions : UHF Windshield Tag Wiegand 26 - 106,4 mm x 28,6 mm (4 3/16 in x1 1/8 in), UHF Windshield Tag Wiegand 26 (US) - 106,4 mm x 28,6 mm (4 3/16 in x1 1/8 in), UHF Windshield Tag - 90 x 27 mm (3.5 x 1.06 in), UHF Windshield Tag Tamper Resistant Wiegand 26 - 106,4 mm x 28,6 mm (4 3/16 in x1 1/8 in), UHF Windshield Tag Tamper Resistant Wiegand 26 (US) - 106,4 mm x 28,6 mm (43/16 in x1 1/8 in), UHF Windshield Tag Tamper Resistant - 90 x 27 mm (3.5 x 1.06 in)
    • Color : White with printing
    • Weight : 1 g (0.04 lbs)
    • Protection class : IP54 (approx. NEMA 2)
    • Material : Polyester
    • Customization : Customized tag printing available on request. Optional Barcode 39 printed on the tag on request.
    • Operating temperature : -20 ... +70°C (-4 … +158°F)
    • Storage temperature : -20 ... +70°C (-4 … +158°F)
    • Relative humidity : 10% ... 93% relative humidity, non-condensing
    • Read range : up to 10 meters (33 feet) with uPASS Target, up to 5 meters (16 feet) with Upass Reach
    • Operating frequency : 865 - 870 MHz / 902 - 928 MHz
    • Mounting : Onto the windshield, the tag is featured with a standard pressure-sensitive adhesive back
    • Compatible readers : 9217363 uPASS Target (region 1), 9217371 uPASS Target (region 2&3), 9942319 uPASS Reach (region 1), 9945466 uPASS Reach (region 2&3)
